Spark on Nebula Graph

Wey Gu  included in  category Nebula Graph
     2778 words  14 minutes
What could be done with Spark and PySpark on top of Nebula Graph, this post covers everything we should know.

What could be done with Spark and PySpark on top of Nebula Graph, this post covers everything we should know.

In this article, I am trying to walk you through all three Spark projects of Nebula Graph with some runnable hands-on examples. Also, I managed to make PySpark usable with Nebula Graph Spark Connector, which will be contributed to the Docs later.

I used to draw a sketch around all data importing methods of Nebula Graph here, where all three of the Spark-based Nebula Graph projects were already briefly introduced. Instead, in this article, a slightly deeper dive into all of them will be made based on my recent work on them.

TL;DR

  • Nebula Spark Connector is a Spark Lib to enable spark application reading from and writing to Nebula Graph in form of a dataframe.
  • Nebula Exchange, built on top of Nebula Spark Connector, is a Spark Lib and Application to exchange(for the Open Source version, it’s one way: write, whereas for the enterprise version it’s bidirectional) different data sources like(MySQL, Neo4j, PostgreSQL, Clickhouse, Hive, etc.). Besides writing directly to Nebula Graph, it could optionally generate SST files to be ingested into Nebula Graph to offload the storage computation outside of the Nebula Graph cluster.
  • Nebula Algorithm, built on top of Nebula Spark Connector and GraphX, is a Spark Lib and Application to run de facto graph algorithms(PageRank, LPA, etc…) on a graph from Nebula Graph.

Then let’s have the long version of those spark projects more on how-to perspectives.

To read data from Nebula Graph, i.e. vertex, Nebula Spark Connector will scan all storage instances that hold the given label(TAG): withLabel("player"), and we could optionally specify the properties of the vertex: withReturnCols(List("name", "age")).

With needed configuration being provided, a call of spark.read.nebula.loadVerticesToDF will return dataframe of the Vertex Scan call towards Nebula Graph:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22

  def readVertex(spark: SparkSession): Unit = {
    LOG.info("start to read nebula vertices")
    val config =
      NebulaConnectionConfig
        .builder()
        .withMetaAddress("metad0:9559,metad1:9559,metad2:9559")
        .withConenctionRetry(2)
        .build()
    val nebulaReadVertexConfig: ReadNebulaConfig = ReadNebulaConfig
      .builder()
      .withSpace("basketballplayer")
      .withLabel("player")
      .withNoColumn(false)
      .withReturnCols(List("name", "age"))
      .withLimit(10)
      .withPartitionNum(10)
      .build()
    val vertex = spark.read.nebula(config, nebulaReadVertexConfig).loadVerticesToDF()
    vertex.printSchema()
    vertex.show(20)
    println("vertex count: " + vertex.count())
  }

It’s similar for the writer part and one big difference here is the writing path is done via GraphD as the underlying Spark Connector is shooting nGQL INSERT queries.

Then let’s do the hands-on end-to-end practice.

Prerequisites: it’s assumed below the procedure is being run on a Linux Machine with an internet connection, ideally with Docker and Docker-Compose preinstalled.

Firstly, let’s deploy Nebula Graph Core v3.0 and Nebula Studio with Nebula-Up, it will try to install Docker and Docker-Compose for us, in case it failed, please try to install Docker and Docker-Compose on your own first.

1

curl -fsSL nebula-up.siwei.io/install.sh | bash -s -- v3.0

After the above script is executed, let’s connect to it with Nebula-Console, the command line client for Nebula Graph.

  • Enter the container with the console
1

~/.nebula-up/console.sh
  • Connect to the Nebula Graph
1

nebula-console -addr graphd -port 9669 -user root -p nebula

1
2

ADD HOSTS "storaged0":9779,"storaged1":9779,"storaged2":9779;
SHOW HOSTS;

1

:play basketballplayer;

Thanks to Big data europe, it’s quite handly to do so:

1
2
3
4

docker run --name spark-master-0 --network nebula-docker-compose_nebula-net \
    -h spark-master-0 -e ENABLE_INIT_DAEMON=false -d \
    -v ${PWD}/:/root \
    bde2020/spark-master:2.4.5-hadoop2.7

In the above one line command, we created a container named spark-master-0 with a built-in Hadoop 2.7 and spark 2.4.5, connected to the Nebula Graph cluster in its docker network named nebula-docker-compose_nebula-net, and it mapped the current path to /root of the spark container.

Then, we could access the spark env container with:

1

docker exec -it spark-master-0 bash

Optionally, we could install mvn inside the container:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

docker exec -it spark-master-0 bash
# in the container shell

export MAVEN_VERSION=3.5.4
export MAVEN_HOME=/usr/lib/mvn
export PATH=$MAVEN_HOME/bin:$PATH

wget http://archive.apache.org/dist/maven/maven-3/$MAVEN_VERSION/binaries/apache-maven-$MAVEN_VERSION-bin.tar.gz && \
  tar -zxvf apache-maven-$MAVEN_VERSION-bin.tar.gz && \
  rm apache-maven-$MAVEN_VERSION-bin.tar.gz && \
  mv apache-maven-$MAVEN_VERSION /usr/lib/mvn

Let’s clone the connector and the example code base, and build(or place the connector Jar package) the connector:

1
2
3
4
5
6

git clone https://github.com/vesoft-inc/nebula-spark-connector.git

docker exec -it spark-master-0 bash
cd /root/nebula-spark-connector

/usr/lib/mvn/bin/mvn install -Dgpg.skip -Dmaven.javadoc.skip=true -Dmaven.test.skip=true

Then we replace the example code:

1

vi example/src/main/scala/com/vesoft/nebula/examples/connector/NebulaSparkReaderExample.scala

We put the code as the following, where two functions readVertex and readEdges was created on the basketballplayer graph space:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81

package com.vesoft.nebula.examples.connector

import com.facebook.thrift.protocol.TCompactProtocol
import com.vesoft.nebula.connector.connector.NebulaDataFrameReader
import com.vesoft.nebula.connector.{NebulaConnectionConfig, ReadNebulaConfig}
import org.apache.spark.SparkConf
import org.apache.spark.sql.SparkSession
import org.slf4j.LoggerFactory

object NebulaSparkReaderExample {

  private val LOG = LoggerFactory.getLogger(this.getClass)

  def main(args: Array[String]): Unit = {

    val sparkConf = new SparkConf
    sparkConf
      .set("spark.serializer", "org.apache.spark.serializer.KryoSerializer")
      .registerKryoClasses(Array[Class[_]](classOf[TCompactProtocol]))
    val spark = SparkSession
      .builder()
      .master("local")
      .config(sparkConf)
      .getOrCreate()

    readVertex(spark)
    readEdges(spark)

    spark.close()
    sys.exit()
  }

  def readVertex(spark: SparkSession): Unit = {
    LOG.info("start to read nebula vertices")
    val config =
      NebulaConnectionConfig
        .builder()
        .withMetaAddress("metad0:9559,metad1:9559,metad2:9559")
        .withConenctionRetry(2)
        .build()
    val nebulaReadVertexConfig: ReadNebulaConfig = ReadNebulaConfig
      .builder()
      .withSpace("basketballplayer")
      .withLabel("player")
      .withNoColumn(false)
      .withReturnCols(List("name", "age"))
      .withLimit(10)
      .withPartitionNum(10)
      .build()
    val vertex = spark.read.nebula(config, nebulaReadVertexConfig).loadVerticesToDF()
    vertex.printSchema()
    vertex.show(20)
    println("vertex count: " + vertex.count())
  }

  def readEdges(spark: SparkSession): Unit = {
    LOG.info("start to read nebula edges")

    val config =
      NebulaConnectionConfig
        .builder()
        .withMetaAddress("metad0:9559,metad1:9559,metad2:9559")
        .withTimeout(6000)
        .withConenctionRetry(2)
        .build()
    val nebulaReadEdgeConfig: ReadNebulaConfig = ReadNebulaConfig
      .builder()
      .withSpace("basketballplayer")
      .withLabel("follow")
      .withNoColumn(false)
      .withReturnCols(List("degree"))
      .withLimit(10)
      .withPartitionNum(10)
      .build()
    val edge = spark.read.nebula(config, nebulaReadEdgeConfig).loadEdgesToDF()
    edge.printSchema()
    edge.show(20)
    println("edge count: " + edge.count())
  }

}

Then build it:

1
2

cd example
/usr/lib/mvn/bin/mvn install -Dgpg.skip -Dmaven.javadoc.skip=true -Dmaven.test.skip=true

Execute it on spark:

1
2
3

/spark/bin/spark-submit --master "local" \
    --class com.vesoft.nebula.examples.connector.NebulaSparkReaderExample \
    --driver-memory 16g target/example-3.0-SNAPSHOT.jar

And the result should include:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53

22/04/19 07:29:34 INFO DAGScheduler: Job 1 finished: show at NebulaSparkReaderExample.scala:57, took 0.199310 s
+---------+------------------+---+
|_vertexId|              name|age|
+---------+------------------+---+
|player105|       Danny Green| 31|
|player109|    Tiago Splitter| 34|
|player111|        David West| 38|
|player118| Russell Westbrook| 30|
|player143|Kristaps Porzingis| 23|
|player114|     Tracy McGrady| 39|
|player150|       Luka Doncic| 20|
|player103|          Rudy Gay| 32|
|player113|   Dejounte Murray| 29|
|player121|        Chris Paul| 33|
|player128|   Carmelo Anthony| 34|
|player130|       Joel Embiid| 25|
|player136|        Steve Nash| 45|
|player108|        Boris Diaw| 36|
|player122|    DeAndre Jordan| 30|
|player123|       Ricky Rubio| 28|
|player139|        Marc Gasol| 34|
|player142|     Klay Thompson| 29|
|player145|      JaVale McGee| 31|
|player102| LaMarcus Aldridge| 33|
+---------+------------------+---+
only showing top 20 rows

22/04/19 07:29:36 INFO DAGScheduler: Job 4 finished: show at NebulaSparkReaderExample.scala:82, took 0.135543 s
+---------+---------+-----+------+
|   _srcId|   _dstId|_rank|degree|
+---------+---------+-----+------+
|player105|player100|    0|    70|
|player105|player104|    0|    83|
|player105|player116|    0|    80|
|player109|player100|    0|    80|
|player109|player125|    0|    90|
|player118|player120|    0|    90|
|player118|player131|    0|    90|
|player143|player150|    0|    90|
|player114|player103|    0|    90|
|player114|player115|    0|    90|
|player114|player140|    0|    90|
|player150|player120|    0|    80|
|player150|player137|    0|    90|
|player150|player143|    0|    90|
|player103|player102|    0|    70|
|player113|player100|    0|    99|
|player113|player101|    0|    99|
|player113|player104|    0|    99|
|player113|player105|    0|    99|
|player113|player106|    0|    99|
+---------+---------+-----+------+
only showing top 20 rows

And there are more examples under the repo, especially one for GraphX, you could try exploring yourself for that part. Please be noted in GraphX assumed vertex ID to be in numeric type, thus for string typed vertex ID case a conversion on the fly is needed, please refer to the example in Nebula Algorithom on how to mitigate that.

Nebula Exchange is a Spark Lib/App to read data from multiple sources, then, write to either Nebula Graph directly or into Nebula Graph SST Files.

https://docs.nebula-graph.io/3.0.2/nebula-exchange/figs/ex-ug-003.png

The way to leverage Nebula Exchange is only to firstly create the configuration files to let the exchange know how data should be fetched and written, then call the exchange package with the conf file specified.

Now let’s do a hands-on test with the same environment created in the last chapter.

Here, we are using Exchange to consume data source from a CSV file, where the first column is Vertex ID, and the second, and third to be properties of “name” and “age”.

1
2

player800,"Foo Bar",23
player801,"Another Name",21
  • Let’s get into the spark container created in the last chapter, and download the Jar package of Nebula Exchange:
1
2
3
4
5

docker exec -it spark-master bash
cd /root/

wget https://github.com/vesoft-inc/nebula-exchange/releases/download/v3.0.0/nebula-exchange_spark_2.4-3.0.0.jar
  • Create a conf file named exchange.conf in format HOCON, where:
    • under .nebula, information regarding Nebula Graph Cluster was configured
    • under .tags, information regarding Vertices like how required fields are reflected our data source(here it’s CSV file) was configured
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90

{
  # Spark relation config
  spark: {
    app: {
      name: Nebula Exchange
    }

    master:local

    driver: {
      cores: 1
      maxResultSize: 1G
    }

    executor: {
        memory: 1G
    }

    cores:{
      max: 16
    }
  }

  # Nebula Graph relation config
  nebula: {
    address:{
      graph:["graphd:9669"]
      meta:["metad0:9559", "metad1:9559", "metad2:9559"]
    }
    user: root
    pswd: nebula
    space: basketballplayer

    # parameters for SST import, not required
    path:{
        local:"/tmp"
        remote:"/sst"
        hdfs.namenode: "hdfs://localhost:9000"
    }

    # nebula client connection parameters
    connection {
      # socket connect & execute timeout, unit: millisecond
      timeout: 30000
    }

    error: {
      # max number of failures, if the number of failures is bigger than max, then exit the application.
      max: 32
      # failed import job will be recorded in output path
      output: /tmp/errors
    }

    # use google's RateLimiter to limit the requests send to NebulaGraph
    rate: {
      # the stable throughput of RateLimiter
      limit: 1024
      # Acquires a permit from RateLimiter, unit: MILLISECONDS
      # if it can't be obtained within the specified timeout, then give up the request.
      timeout: 1000
    }
  }

  # Processing tags
  # There are tag config examples for different data Sources.
  tags: [

    # HDFS CSV
    # Import mode is client, just change type.sink to sst if you want to use client import mode.
    {
      name: player
      type: {
        source: csv
        sink: client
      }
      path: "file:///root/player.csv"
      # if your csv file has no header, then use _c0,_c1,_c2,.. to indicate fields
      fields: [_c1, _c2]
      nebula.fields: [name, age]
      vertex: {
        field:_c0
      }
      separator: ","
      header: false
      batch: 256
      partition: 32
    }

  ]
}
  • Finally, let’s create player.csv and exchange.conf, it should be listed as the following:
1
2
3
4
5

# ls -l

-rw-r--r--    1 root     root          1912 Apr 19 08:21 exchange.conf
-rw-r--r--    1 root     root     157814140 Apr 19 08:17 nebula-exchange_spark_2.4-3.0.0.jar
-rw-r--r--    1 root     root            52 Apr 19 08:06 player.csv
  • And we could call the exchange as:
1
2
3

/spark/bin/spark-submit --master local \
    --class com.vesoft.nebula.exchange.Exchange nebula-exchange_spark_2.4-3.0.0.jar \
    -c exchange.conf

And the result should be like

1
2
3
4
5

...
22/04/19 08:22:08 INFO Exchange$: import for tag player cost time: 1.32 s
22/04/19 08:22:08 INFO Exchange$: Client-Import: batchSuccess.player: 2
22/04/19 08:22:08 INFO Exchange$: Client-Import: batchFailure.player: 0
...

Please refer to the documentation and conf examples for more data sources. For hands-on Exchange writing to SST Files, you could refer to both Documentation and Nebula Exchange SST 2.x Hands-on Guide.

When we call Nebula Algorithm with spark-submit, on how to use perspective, it is quite similar to Exchange. This post already showed us how to do that in action.

On the other hand, we could call Nebula Algorithm in spark as a Spark Lib, the gain will be:

  1. More control/customization on the output format of the algorithm
  2. Possible to perform algorithm for non-numerical vertex ID cases, see here

PySpark comes with the capability to call java/scala packages inside python, thus it’s also quite easy to use Spark Connector with Python.

Here I am doing this from the pyspark entrypoint in /spark/bin/pyspark, with the connector’s Jar package specified with --driver-class-path and --jars

1
2
3
4
5

docker exec -it spark-master-0 bash
cd root
wget https://repo1.maven.org/maven2/com/vesoft/nebula-spark-connector/3.0.0/nebula-spark-connector-3.0.0.jar

/spark/bin/pyspark --driver-class-path nebula-spark-connector-3.0.0.jar --jars nebula-spark-connector-3.0.0.jar

Then, rather than pass NebulaConnectionConfig and ReadNebulaConfig to spark.read.nebula, we should instead call spark.read.format("com.vesoft.nebula.connector.NebulaDataSource").

Voilà!

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

df = spark.read.format(
  "com.vesoft.nebula.connector.NebulaDataSource").option(
    "type", "vertex").option(
    "spaceName", "basketballplayer").option(
    "label", "player").option(
    "returnCols", "name,age").option(
    "metaAddress", "metad0:9559").option(
    "partitionNumber", 1).load()

>>> df.show(n=2)
+---------+--------------+---+
|_vertexId|          name|age|
+---------+--------------+---+
|player105|   Danny Green| 31|
|player109|Tiago Splitter| 34|
+---------+--------------+---+
only showing top 2 rows

Below are how I figured out how to make this work with almost zero scala knowledge:-P.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31

      def loadVerticesToDF(): DataFrame = {
        assert(connectionConfig != null && readConfig != null,
               "nebula config is not set, please call nebula() before loadVerticesToDF")
        val dfReader = reader
          .format(classOf[NebulaDataSource].getName)
          .option(NebulaOptions.TYPE, DataTypeEnum.VERTEX.toString)
          .option(NebulaOptions.SPACE_NAME, readConfig.getSpace)
          .option(NebulaOptions.LABEL, readConfig.getLabel)
          .option(NebulaOptions.PARTITION_NUMBER, readConfig.getPartitionNum)
          .option(NebulaOptions.RETURN_COLS, readConfig.getReturnCols.mkString(","))
          .option(NebulaOptions.NO_COLUMN, readConfig.getNoColumn)
          .option(NebulaOptions.LIMIT, readConfig.getLimit)
          .option(NebulaOptions.META_ADDRESS, connectionConfig.getMetaAddress)
          .option(NebulaOptions.TIMEOUT, connectionConfig.getTimeout)
          .option(NebulaOptions.CONNECTION_RETRY, connectionConfig.getConnectionRetry)
          .option(NebulaOptions.EXECUTION_RETRY, connectionConfig.getExecRetry)
          .option(NebulaOptions.ENABLE_META_SSL, connectionConfig.getEnableMetaSSL)
          .option(NebulaOptions.ENABLE_STORAGE_SSL, connectionConfig.getEnableStorageSSL)

        if (connectionConfig.getEnableStorageSSL || connectionConfig.getEnableMetaSSL) {
          dfReader.option(NebulaOptions.SSL_SIGN_TYPE, connectionConfig.getSignType)
          SSLSignType.withName(connectionConfig.getSignType) match {
            case SSLSignType.CA =>
              dfReader.option(NebulaOptions.CA_SIGN_PARAM, connectionConfig.getCaSignParam)
            case SSLSignType.SELF =>
              dfReader.option(NebulaOptions.SELF_SIGN_PARAM, connectionConfig.getSelfSignParam)
          }
        }

        dfReader.load()
      }

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69

#

object NebulaOptions {

  /** nebula common config */
  val SPACE_NAME: String    = "spaceName"
  val META_ADDRESS: String  = "metaAddress"
  val GRAPH_ADDRESS: String = "graphAddress"
  val TYPE: String          = "type"
  val LABEL: String         = "label"

  /** connection config */
  val TIMEOUT: String            = "timeout"
  val CONNECTION_RETRY: String   = "connectionRetry"
  val EXECUTION_RETRY: String    = "executionRetry"
  val RATE_TIME_OUT: String      = "reteTimeOut"
  val USER_NAME: String          = "user"
  val PASSWD: String             = "passwd"
  val ENABLE_GRAPH_SSL: String   = "enableGraphSSL"
  val ENABLE_META_SSL: String    = "enableMetaSSL"
  val ENABLE_STORAGE_SSL: String = "enableStorageSSL"
  val SSL_SIGN_TYPE: String      = "sslSignType"
  val CA_SIGN_PARAM: String      = "caSignParam"
  val SELF_SIGN_PARAM: String    = "selfSignParam"

  /** read config */
  val RETURN_COLS: String      = "returnCols"
  val NO_COLUMN: String        = "noColumn"
  val PARTITION_NUMBER: String = "partitionNumber"
  val LIMIT: String            = "limit"

  /** write config */
  val RATE_LIMIT: String   = "rateLimit"
  val VID_POLICY: String   = "vidPolicy"
  val SRC_POLICY: String   = "srcPolicy"
  val DST_POLICY: String   = "dstPolicy"
  val VERTEX_FIELD         = "vertexField"
  val SRC_VERTEX_FIELD     = "srcVertexField"
  val DST_VERTEX_FIELD     = "dstVertexField"
  val RANK_FIELD           = "rankFiled"
  val BATCH: String        = "batch"
  val VID_AS_PROP: String  = "vidAsProp"
  val SRC_AS_PROP: String  = "srcAsProp"
  val DST_AS_PROP: String  = "dstAsProp"
  val RANK_AS_PROP: String = "rankAsProp"
  val WRITE_MODE: String   = "writeMode"

  val DEFAULT_TIMEOUT: Int            = 3000
  val DEFAULT_CONNECTION_TIMEOUT: Int = 3000
  val DEFAULT_CONNECTION_RETRY: Int   = 3
  val DEFAULT_EXECUTION_RETRY: Int    = 3
  val DEFAULT_USER_NAME: String       = "root"
  val DEFAULT_PASSWD: String          = "nebula"

  val DEFAULT_ENABLE_GRAPH_SSL: Boolean   = false
  val DEFAULT_ENABLE_META_SSL: Boolean    = false
  val DEFAULT_ENABLE_STORAGE_SSL: Boolean = false

  val DEFAULT_LIMIT: Int = 1000

  val DEFAULT_RATE_LIMIT: Long    = 1024L
  val DEFAULT_RATE_TIME_OUT: Long = 100
  val DEFAULT_POLICY: String      = null
  val DEFAULT_BATCH: Int          = 1000

  val DEFAULT_WRITE_MODE = WriteMode.INSERT

  val EMPTY_STRING: String = ""
}

feature image credit: Sander

Related Content

Deme: Graph RAG, the new LLM Stack

Deme: Build Knowledge Graph and Text2Cypher in NebulaGraph

What could be done with Spark and PySpark on top of Nebula Graph, this post covers everything we should know.

Text2Cypher, the beginning of the Graph + LLM stack

What could be done with Spark and PySpark on top of Nebula Graph, this post covers everything we should know.

NebulaGraph in Jupyter Notebook

What could be done with Spark and PySpark on top of Nebula Graph, this post covers everything we should know.

Graph Enabled Llama Index

Updated on 2023-09-07  bf91cda
Read markdown | Report issue
 Nebula Graph, Spark, PySpark
Back | Home
